Secondary khib 4 Spool
Taw qhia
Qhov thib ob khib 4 spool yog ib qho insulator bracket nrog lub hauv paus steel nyob rau hauv qab. Lub hauv paus yog txuas nrog tus ncej los ntawm cov txiv ntseej thiab bolts. Secondary khib 4 spool yog galvanized thiab ua raws li ASTM-123 cov qauv. Nws yog tsim los txhawb plaub insulators.
Insulator post struts yog sib npaug kom paub tseeb tias nws yuav tsis ua puas tsuaj rau rwb thaiv tsev thaum hlua. Struts yog hluav taws xob yog welded thiab riveted rau hnyav thiab nruab nrab lub luag hauj lwm chav kawm feem.
ANSI chav kawm 52-3 thiab 52-2 insulator yuav haum rau qhov hnyav thiab nruab nrab lub luag haujlwm khib raws li.
Specifications
|
Catalog No. |
No. Ntawm Hlau |
Dimensions hauv Inches |
Kwv yees li. Nkoj Wt. Lbs. Rau 100pcs |
||
|
End Mtg. Qhov sib nrug |
Zuag qhia tag nrho ntev, Rov qab |
Dav ntawm Back |
|||
|
C2070047 |
3 |
24 |
18 |
2 7/8 |
660 |
|
C2070048 |
4 |
32 |
34 |
2 7/8 |
880 |
Khoom nthuav dav
- Lub npe: Secondary khib 4 spool
- Khoom siv:Hlau
- Txheej:Galvanized, ASTM A -153
- Keeb kwm: Zhejiang, Suav teb
- Lub sij hawm them nyiaj:TT, LC
- Kev ua lag luam:Philippines/America/North America/Thailand
Daim ntawv thov
Secondary rack 4 spool yog dav siv nyob rau hauv ntau yam fais fab kis tau tus mob, tshwj xeeb tshaj yog nyob rau hauv kev tsim kho ntawm lub nroog hwj chim daim phiaj thiab nyob deb nroog fais fab tuag. Nws muaj peev xwm txhawb nqa ruaj khov thiab kev ua haujlwm zoo rwb thaiv tsev ua rau nws yog ib feem tseem ceeb ntawm lub zog hluav taws xob. Tsis tas li ntawd, qhov thib ob nyiaj siv ua haujlwm cable txhawb nqa ncej kuj tseem siv tau rau lwm lub sijhawm uas xav tau kev txhawb nqa cable, xws li cov kab sib txuas lus, teeb pom kev, thiab lwm yam.
Ntim
Kev txhim kho thiab kho
Cov txheej txheem kev teeb tsa ntawm cov nyiaj siv hluav taws xob txuas ntxiv txuas ntxiv yog qhov yooj yim. Ua ntej, lub hauv paus yuav tsum tau kho ib nrab rau lub hwj chim ncej, thiab tom qab ntawd cov ncej txhawb nqa txuas nrog lub hauv paus los ntawm bolts thiab ceev. Thaum lub sij hawm installation, xyuas kom meej tias tag nrho cov connectors muaj kev ruaj ntseg zoo kom tsis txhob muaj kev nyab xeeb txaus ntshai tshwm sim los ntawm loosening. Nyob rau hauv cov nqe lus ntawm kev txij nkawm, nws yog ib qho tsim nyog yuav tsum tsis tu ncua xyuas qhov kev ncaj ncees ntawm qhov kev sib txuas ntawm cov ncej txhawb nqa thiab cov txheej txheem galvanized los xyuas kom meej tias nws txoj haujlwm ruaj khov mus ntev.
